◇ PES membrane featured with excellent hydrophilization

◇ Mirrored asymmetric structure

◇ Polyethersulfone membrane is permanently hydrophilic membrane without use of additives, surface active agents or post-treatments

◇ The highly porous asymmetric membrane ensure lower pressure drop,greater throughput and extended service life

◇ Manufacture in clean room, high clean cartridge

◇ Assurance of product integrity test and effectiveness in operation

◇ End caps and connectors sealed by thermal bond, free of binder

◎ Material: Polyethersulfone hydrophilic membrane

◎ Support: Polypropylene

◎ Micron Rating: 0.04, 0.1, 0.2, 0.45, 0.65, 1.2 Micron

◎ Inner diameter/ Outer diameter: 28 mm / 69 mm；28 mm / 83mm

◎ Maximum operating forward pressure: 80°C：1.7 bar 20°C：5.5 bar²

◎ Maximum operating forward pressure: 80°C

◎ Filtration Area: 0.62m2 (10”)

◎ Sterilizatic: Autoclave: 121°C, 30 min, 10 times Steam: 121°C, 30 min, 10 times Hot water: 80°C, 30min 30 times
